PEEK Rods and Sheets

PEEK rods and sheets are high-performance engineering plastic stock shapes designed for machining components that require high mechanical strength, heat resistance, dimensional stability and chemical resistance.

PEEK, or polyetherether ketone, combines the rigidity and strength of an engineering plastic with excellent performance in demanding temperature, pressure and chemical environments. It is widely used as an alternative to metal and conventional plastics in applications where lower weight, electrical insulation, wear resistance or corrosion resistance is required.

We supply PEEK round rods in diameters from 2 mm to 250 mm, with a standard length of 1000 mm. PEEK sheets are available in thicknesses from 1 mm to 100 mm, with a standard sheet size of 620 × 1220 mm.

Custom cutting, non-standard dimensions and CNC-machined components can be supplied according to drawings or application requirements.

Available Product Forms

PEEK Rod

PEEK rod is suitable for CNC turning, milling, drilling and precision machining.

Available dimensions:

• Diameter: Ø2–250 mm
• Standard length: 1000 mm
• Custom length: Available
• Cut-to-length service: Available

PEEK Sheet

PEEK sheet is suitable for machining plates, structural parts, insulating components and wear-resistant parts.

Available dimensions:

• Thickness: 1–100 mm
• Standard sheet size: 620 × 1220 mm
• Custom cutting: Available
• Machined components: Available

Key Features

• High mechanical strength
• Excellent heat resistance
• Good dimensional stability
• Good chemical resistance
• High wear and abrasion resistance
• Low moisture absorption
• Good electrical-insulation properties
• Suitable for repeated machining and precision components
• Lower weight than many metal alternatives
• Good fatigue and creep resistance
• PEEK rods and sheets available
• Custom cutting and CNC machining available

Standard Dimensions

PEEK Rod Specifications

Available Material Grades

Virgin PEEK

Virgin PEEK provides a balanced combination of:

• Mechanical strength
• Chemical resistance
• Electrical insulation
• Dimensional stability
• Natural beige appearance

Glass-Filled PEEK

Glass-fiber-filled PEEK may provide:

• Increased rigidity
• Reduced thermal expansion
• Improved dimensional stability
• Higher structural strength

Carbon-Filled PEEK

Carbon-filled PEEK may provide:

• Improved wear resistance
• Higher stiffness
• Better thermal conductivity
• Reduced static accumulation, depending on grade

Bearing-Grade PEEK

Bearing-grade PEEK may contain fillers designed to improve:

• Sliding performance
• Wear resistance
• Friction characteristics
• Service life in moving components

Material grade should be selected according to mechanical load, temperature, wear conditions, electrical requirements and chemical exposure.

Typical Applications

PEEK rods and sheets can be machined into:

• Bushings and bearings
• Seals and sealing rings
• Valve components
• Pump components
• Electrical-insulation parts
• Structural brackets
• Wear plates
• Guide rails
• Semiconductor equipment parts
• Medical instrument components
• Aerospace components
• Automotive components
• Laboratory equipment parts
• Precision gears
• Compressor components
• Chemical-resistant mechanical parts

Application Industries

• Semiconductor manufacturing
• Aerospace and aviation
• Medical equipment
• Automotive manufacturing
• Chemical processing
• Electronics and electrical systems
• Oil and gas equipment
• Food-processing machinery
• Pharmaceutical equipment
• Precision machinery
• Pump and valve manufacturing
• Industrial automation

Suitability for medical, food-contact, semiconductor or aerospace applications depends on the selected raw-material grade and required certification.

PEEK Rods and Sheets vs. Fluoropolymer Stock Shapes

PEEK is often selected when the component needs to withstand mechanical load while maintaining dimensional stability at elevated temperatures.

Custom Machining Services

PEEK rods and sheets can be supplied as raw stock or processed into finished components.

Available services include:

• Cut-to-length rods
• Sheet cutting
• CNC turning
• CNC milling
• Precision drilling
• Thread machining
• Groove machining
• Gear machining
• Bushing and bearing production
• Seal and ring production
• Prototype machining
• Small-batch manufacturing
• Custom dimensional inspection
• Protective packaging

For machined parts, please provide a technical drawing showing dimensions, tolerances, surface finish, material grade and quantity.
