Description

Smooth-bore PTFE hose with 304 stainless steel braiding. Excellent corrosion resistance, high-pressure capability, and stable performance from -70°C to +260°C. Ideal for chemicals, gases, and high-temperature fluid transfer.

Overview

This smooth bore PTFE stainless steel braided hose is designed for industrial applications requiring exceptional corrosion resistance, high pressure tolerance, and stable performance under extreme temperatures.
The inner tube is made from 100% PTFE (Polytetrafluoroethylene), offering a non-stick, low-friction surface that ensures fast flow and minimal residue. The outer 304 stainless steel braid provides superior mechanical strength, abrasion resistance, and enhanced flexibility.

Suitable for chemical plants, gas lines, steam systems, thermal fluid transfer, machinery, and high-purity processing industries.

Key Features & Advantages

1. Superior Corrosion Resistance

PTFE is chemically inert and remains unaffected even when exposed to:

• Aqua regia

• Strong acids & alkalis

• Organic solvents

• Highly corrosive industrial fluids

Ideal for aggressive chemical and gas transfer systems.

2. Wide Temperature Capability (-70°C to +260°C)

The hose maintains structural stability and flow performance under both cryogenic and high-temperature conditions.
✓ No cracking at low temperatures
✓ No deformation under continuous heat
✓ Reliable long-term service

3. 304 Stainless Steel Braided Reinforcement

The stainless-steel outer braid significantly enhances mechanical durability:
✓ Excellent high-pressure resistance
✓ Improved abrasion protection
✓ Smaller bending radius
✓ Better vibration resistance
✓ Longer service life in dynamic systems

4. Smooth Bore, Non-Stick PTFE Inner Surface

The inner PTFE tube provides:
✓ Fast flow with reduced friction
✓ Minimal residue or contamination
✓ Easy cleaning and flushing
✓ No clogging even with viscous or sticky fluids

Perfect for high-purity chemicals, solvents, adhesives, gases, and food-grade applications.

Specifications

Applications

• Chemical transfer lines

• Solvent and corrosive fluid pipelines

• Steam and gas delivery systems

• Mold temperature controllers & injection molding equipment

• Thermal oil and high-temperature fluid circulation

• Pharmaceutical and food-grade processing

• Machinery and equipment protection
